    Single Mode Green Sc Fiber Optic Adapter With Retractable Metal Shutter

    Ask Lasest Price
    Brand Name : ZGT
    Model Number : ZZTAD-SC51-S-1
    Certification : ISO9001,ROSH N Type Attenuator,Telecom
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 900K PER MONTH
    • Product Details
    • Company Profile

    Single Mode Green Sc Fiber Optic Adapter With Retractable Metal Shutter

    Fiber optic Adapter SC SX adapter with retractable metal shutter, flanged low loss

    SC Shutter adapterYou are here: Home > Products > Fiber Optic Shutter adapter

    SC SX adapter with retractable shutter, flanged


    Serial Number: ZZTAD-SC51-S-1

    Competitive Advantage:

    Telcordia GR-326, IEC, TIA/EIA Standard compliant.

    100% Optical performance inspection.

    Low Insertion Loss.

    RoHS Compliance.

    Customized design and production.

    Parts &Material

    Parts

    Material

    Remarks

    Sleeve

    Zirconia, PB

    Housing

    PBT

    Flammability UL94 V-0

    Dust cap

    ABS

    Flammability UL94 V-0

    Shutter

    ABS

    Flammability UL94 V-0

    Meter cover

    Stainless steel

    Optical Performance

    Premium Grade

    Standard Grade

    Insertion Loss

    ≤0.1dB

    ≤0.2dB

    Durability

    1000 times

    1000 times

    Enviroment and Mechanical

    Properties

    Test condition

    Conformance

    Test result

    Vibration

    10-55Hz, 1.5mm, 60min

    IEC61300-2-1

    ≤0.2dB

    Mating Durability

    1000 Mating, clean every 25 mating.

    IEC61300-2-2

    ≤0.2dB

    Impact

    1.5m, 8 drops

    IEC61300-2-6

    ≤0.2dB

    Strength of Coupling Mechanism

    40N, 10Min, L=22-28cm

    IEC61300-2-12

    ≤0.2dB

    Temperature Cycling

    40C to +75C, 40 cy
